For riders who want more out of every mile, the 2026 Low Rider S brings a sharper edge to factory performance. From its rip-ready suspension to the Heavy Breather intake and performance-tuned 2-into-1 exhaust, this machine is built to cut harder, corner sharper, and rev to the limiter. And with the Milwaukee-Eight® 117 High Output motor and standard Rider Safety Enhancements, it’ll let you ride like you were born for it.

Specifications

  • Dimensions
    add remove
    • Length:
      92.9 in
    • Seat height, unladen:
      28.1 in
    • Rake (steering head):
      28
    • Trail:
      5.7 in
    • Wheelbase:
      63.6 in
    • Tires, front specifications:
      110/90B19,62H,BW
    • Tires, rear specifications:
      180/70B16,77H,BW
    • Fuel Capacity:
      5.0 gal
    • Oil capacity:
      5 qt.
    • Weight, as shipped:
      644 lbs
    • Weight, in running order:
      670 lb
    • Tire, type:
      Michelin® Scorcher 31, front and rear
  • Engine
    add remove
    • Engine:
      Milwaukee-Eight® 117 High-Output
    • Bore:
      4.1 in
    • Stroke:
      4.5 in
    • Displacement:
      117.35 in3
    • Compression ratio:
      10.3:1
    • Fuel system:
      Electronic Sequential Port Fuel Injection (ESPFI)
    • Exhaust:
      2-into-1; catalyst in header
  • Performance
    add remove
    • Engine torque testing method:
      J1349
    • Engine torque:
      128.3 ft-lb
    • Engine torque (RPM):
      4000
    • Horsepower:
      114 HP / 85 kW @ 5000 rpm
    • Lean angle, right (deg.):
      31.3
    • Lean angle, left (deg.):
      31.3
    • Fuel economy testing method:
      Estimated City/Hwy
    • Fuel economy:
      47 mpg (5 l/100km)
  • Powertrain
    add remove
    • Primary drive:
      Chain, 34/46 ratio
    • Gear ratios (overall) 1st:
      9.311
    • Gear ratios (overall) 2nd:
      6.454
    • Gear ratios (overall) 3rd:
      4.793
    • Gear ratios (overall) 4th:
      3.882
    • Gear ratios (overall) 5th:
      3.307
    • Gear Ratios (overall) 6th:
      2.79
  • Chassis
    add remove
    • Front fork:
      Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
    • Rear shocks:
      Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
    • Wheels, front type:
      Black, Radiate Cast Aluminum
    • Wheels, rear type:
      Black, Radiate Cast Aluminum
    • Brakes, type:
      Front and rear black, Split 7-spoke floating rotors
    • Brakes, caliper type:
      4-piston fixed front and 2-piston floating rear
