A full-dresser, long-haul trike with room for cargo, the Tri Glide Ultra is available in classic chrome or all-new dark finishes. Load up the trunk and King Tour-Pak® luggage carrier with amenities for days on the road and enjoy the comfort and confidence of three-wheels on your greatest adventures.

Specifications

  • Dimensions
    add remove
    • Length:
      105.1 in
    • Seat height, unladen:
      28.9 in
    • Ground clearance:
      4.9 in
    • Rake (steering head):
      26
    • Trail:
      4.0 in
    • Wheelbase:
      65.7 in
    • Tires, front specifications:
      MT 130/60B19 M/C 61H
    • Tires, rear specifications:
      P215/45R18 83T
    • Fuel Capacity:
      6.0 gal
    • Oil capacity:
      5 qt.
    • Weight, as shipped:
      1,199 lbs
    • Weight, in running order:
      1237 lb
    • Luggage capacity – volume:
      6.8 cu ft (0.19 m3)
    • Tire, type:
      Dunlop® Harley-Davidson Series, bias blackwall front and radial blackwall rear
  • Engine
    add remove
    • Engine:
      Twin-Cooled™ Milwaukee-Eight® 114
    • Bore:
      4.0 in
    • Stroke:
      4.5 in
    • Displacement:
      113.99 in3
    • Compression ratio:
      10.5:1
    • Fuel system:
      Electronic Sequential Port Fuel Injection (ESPFI)
    • Exhaust:
      2-1-2 dual exhaust with tapered mufflers
  • Performance
    add remove
    • Engine torque testing method:
      EC 134/2014
    • Engine torque:
      120.2 ft-lb
    • Engine torque (RPM):
      2500
    • Horsepower:
      93 HP / 69 kW @ 5020 rpm
    • Fuel economy testing method:
      EU 134/2014
    • Fuel economy:
    • Fuel economy:
      42 mpg (5.6 l/100km)
  • Powertrain
    add remove
    • Primary drive:
      Chain, 34/46 ratio
    • Gear ratios (overall) 1st:
      10.534
    • Gear ratios (overall) 2nd:
      7.302
    • Gear ratios (overall) 3rd:
      5.423
    • Gear ratios (overall) 4th:
      4.392
    • Gear ratios (overall) 5th:
      3.741
    • Gear Ratios (overall) 6th:
      3.157
  • Chassis
    add remove
    • Front fork:
      49mm dual bending valve
    • Rear shocks:
      Hand-adjustable emulsion rear suspension
    • Wheels, front type:
      Black, 7-spoke Cast Aluminum
    • Wheels, rear type:
      Black, 7-spoke Cast Aluminum
    • Brakes, type:
      Dual floating rotors (front), fixed rotor (rear)
    • Brakes, caliper type:
      Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
  • Infotainment
    add remove
    • Infotainment system:
      Boom!™ Box GTS
    • Type:
      Full Color TFT
    • Watts per channel:
      25
    • Speakers:
      4
    • Speaker size:
      5.25 inch
    • Headset specifications (if equipped):
      16 - 64 ohms
    • AM:
      Standard
    • FM:
      Standard
    • SD Card, Flash Drive and MP3 — via USB Connection:
      Supported
    • Languages:
      English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
    • Hands-free mobile phone — via Bluetooth:
      Standard
    • Voice Recognition Languages: Phone functions only:
      Phone dependent
    • Voice Recognition Languages: Tuner / Media / Navigation:
      Phone dependent
    • Text-to-Speech (TTS) languages:
      Phone dependent
    • Rider / passenger intercom:
      Standard (Passenger Headset Sold Separately)
    • Vehicle information screen:
      Standard
    • USB:
      USB/MTP/iPod/iPhone
    • Bluetooth:
      Phone/Media Supported
